Always work or play with a powerful partner

Offering unbeatable versatility, the lightweight F70 will power a wide range of boat types, so it's equally at home when you're working, or if you're out to experience the fresh air and fun of leisure boating and watersports. In fact, the F70 is the lightest, most powerful 4-stroke in its class.

For cleaner performance, maximum fuel efficiency and easy starting, the powerful 16-valve SOHC engine features EFI (Electronic Fuel Injection) and Yamaha's unique PrimeStart™ system. Compatibility with Yamaha's Digital Network Gauges delivers precise control too.

Sleek and stylish too - your F70 is sure to attract admiring glances from everyone - whether aboard or on the shore.

Technical Specifications

Engine type: 4-stroke
Displacement: 996 cm³
No. of cylinders/configuration: 4/In-line, 16-valve, SOHC
Bore x stroke: 65.0 mm x 75.0 mm
Prop shaft output at mid range: 51.5kW / 5,800 rpm
Full throttle operating range: 5,300 - 6,000 rpm
Lubrication system: Wet sump
Fuel Induction System: EFI
Ignition / advance system: TCI
Starter system: Electric with Prime Start™
Gear ratio: 2.33 (28/12)
Recommended boat transom height: L:534mm X:648mm
Weight with propeller: F70AETL: 119.0 kg, F70AETX: 121.0 kg
Fuel tank capacity: separate, 25 litres
Oil pan capacity: 2.1 litres
Control: Remote Control
Trim & tilt method: Power Trim & Tilt
Lighting Coil / Alternator: 12V - 16A with rectifier/regulator
Tilt limitter (only for remote control specs): Optional
Engine immobiliser: YCOP
Propeller: Optional
Shallow Water Drive: Standard
Digital Network Gauge (Round/Square): Optional
Variable Trolling RPM: With DN Gauges or m-f tiller handle
Shift Dampener System (SDS): Optional
Remark: The kW data in this sheet is based on the ICOMIA 28 standard, measured at the prop shaft
