Harness one of our High-Thrust workhorses

When you want power and handling, FT models are the perfect answer. Ideal for sailing, fishing and working boats, these high-thrust, high-torque engines set new standards of performance, with minimal noise and vibration - and maximum fuel economy.

FT models use Yamaha's patented Dual-Thrust propeller to provide full thrust in Forward and Reverse - making light work of manoeuvring a heavy boat.

While CDI/TCI Micro-computer Ignition offers easy starting and reliability whatever the conditions, the high-output alternator provides extra starting power, even after long periods at low RPM. FT Series engines are efficient, powerful workhorses - designed never to let you down.

Technical Specifications

Engine type: 4-stroke//4-stroke//4-stroke//4-stroke//4-stroke
Displacement: 996 cm³//996 cm³//498 cm³//212 cm³//212 cm³
No. of cylinders/configuration: 4/In-line,SOHC//4/In-line,SOHC//2/In-line,SOHC//2/In-line,SOHC//2/In-line,SOHC
Bore x stroke: 65.0 mm x 75.0 mm//65.0 mm x 75.0 mm//65.0 mm x 75.0 mm//56.0 mm x 43.0 mm//56.0 mm x 43.0 mm
Prop shaft output at mid range: 44.1kW / 5,500 rpm//36.8kW / 5,500 rpm//18.4kW / 5,500 rpm//7.3kW / 5,500 rpm//5.9kW / 5,500 rpm
Full throttle operating range: 5,000 - 6,000 rpm//5,000 - 6,000 rpm//5,000 - 6,000 rpm//5,000 - 6,000 rpm//5,000 - 6,000 rpm
Lubrication system: Wet sump//Wet sump//Wet sump//Wet sump//Wet sump
Fuel Induction System: EFI//EFI//1-Carb//1-Carb//1-Carb
Ignition / advance system: CDI//CDI//CDI//CDI//CDI
Starter system: Electric//Electric//Electric//Manual (MH), Electric (E, EP)//Manual (MH), Electric (E, EP)
Gear ratio: 2.33 (28/12)//2.33 (28/12)//2.42 (29/12)//2.92(/38/13)//2.92/(38/13)
Recommended boat transom height: L:530mm X:644mm//L:530mm//L:536mm//L:557mm X:625mm//L:552mm X:620mm
Weight with propeller: FFT60GETL: 125.0 kg, FT60GETX: 127.0 kg//FT50JETL:125.0 kg//FT25FETL: 92.0 kg//FT9.9LMHL: 45.0 kg, FT9.9LMHX: 46.0 kg, FT9.9LEL: 45.0 kg, FT9.9LEX: 46.0 kg, FT9.9LEPL: 49.0 kg//FT8GMHL: 43.0 kg, FT8GMHX: 44.0 kg, FT8GEL: 44.0 kg, FT8GEX: 45.0 kg, FT8GEPL: 49.0 kg
Fuel tank capacity: separate, 25 litres//separate, 25 litres//separate, 25 litres//separate, 12 litres//separate, 12 litres
Oil pan capacity: 1.9 litres//1.9 litres//1.4 litres//0.8 litres//0.8 litres
Control: Remote Control//Remote Control//Remote Control//Tiller handle (MH), Remote control (E, EP)//Tiller handle (MH), Remote control (E, EP)
Trim & tilt method: Power Trim & Tilt//Power Trim & Tilt//Power Trim & Tilt//Manual Tilt (MH, E), Power Tilt (EP)//Manual Tilt (MH, E), Power Tilt (EP)
Lighting Coil / Alternator: 12V - 16A//12V - 16A//12V - 14A//12V - 6A *optional **//12V - 6A *optional **
Tilt limitter (only for remote control specs): Optional//Optional//-//-//-
Engine immobiliser: YCOP//YCOP//-//-//-
Propeller: Optional//Optional//Optional//Included//Included
Shallow Water Drive: Standard//Standard//Standard//Standard//Standard
Remark: The kW data in this sheet is based on the ICOMIA 28 standard, measured at the prop shaft
