BFT 200

The 200 hp powerful four stroke has a compact 24 valve Single Overhead Cam (SOHC) and narrow V6 design which offers top performance and durability as well as great fuel economy. A Multi-port Programmed Fuel Injection delivers the precise amount of fuel/air to each cylinder. The result is an easy start and instant throttle response. The BFT200 has a high output 90A alternator that produces 60A charging amps. With even more features like Lean Burn Control for better fuel economy at cruising speeds, Boosted Low Speed Torque to deliver an exceptional hole shot and a built-in freshwater flushing system for easy routine flushing, the BFT 200 hp has the reliability and convenience you need but still delivers all the power you want.

Benefits Include:

  • High output 90A alternator that produces 60A charging amps
  • Available in 20" & 25" shaft lengths, standard or counter rotation
  • Double sealed multi-layered paint process to help protect against corrosion
  • Painted interior cooling passages for extra protection against corrosion
  • Ultra-low 3 star CARB emission approved
  • 5 Year limited warranty

4-Stroke Technology

  • Dual stage induction for improved performance
  • Lean burn control for better fuel economy at cruising speeds
  • Boosted low speed torque helps to deliver an exceptional hole shot
  • 3-way cooling system to help protect against overheating
  • Heavy-duty 5" diameter gear case built to withstand extreme conditions
  • Non-linear rubber mounts provide smoother operation at all engine speeds
  • A crankshaft-driven trochoid oil pump ensures long-term durability of critical engine components
  • Multi-port programmed fuel injection delivers the precise amount of fuel/air to each cylinder

Fundamentals for User Convenience and Reliability:

  • Through the prop exhaust for a quieter ride
  • Built-in freshwater flushing system for easy routine flushing
  • Sealed starter motor that is inverted into a sealed chamber to help protect vital components against elements
  • Electronic Control Module protocols allow engine data to be interfaced with on-board systems and systems displays, such as SONAR or GPS

Warning & Protection:

  • Low oil pressure warning
  • Overheat warning
  • Low battery voltage warning
  • Water in fuel warning
  • Start-in-gear protection
  • Over-rev. limiter

Technical Specifications

Engine (No. of Cylinder): 6 Cylinder SOHC, 60˚ V6, 24 Valve
Output: 200 hp (149.1 kw)
Displacement: 3,471 cc (211.7 cu.in.)
Bore x Stroke: 89 x 93 mm (3.5 x 3.7 in)
Starting: Electric
Control Type: Remote Control
Gear Shift: Forward - Neutral - Reverse
Gear Ratio: 1.86:1
Ignition System: MicroComputer Programmed
Transom Height: 20", 25"
Fuel: Unleaded Gasoline (87 Octane) or higher
Oil Type: NMMA Certified FC-W® 4-stroke oil** SAE 10W-30 (SF, SG, SH, SJ)
Oil Capacity: 2.1 gal. (7.8 L) with filter
Weight: 584 lbs. (265 kg)
Alternator Output: 12V, 720W, 90A
Max. RPM Range: 5,000 - 6,000
Programmed Fuel Injection: Standard
Digital CD Ignition System: Standard
Start In Gear Protection: Standard
Thermostat Controlled Cooling System: Standard
Through-The-Prop Exhaust: Standard
Overheat Buzzer: Standard
Oil Pressure Warning: Standard
Power Trim and Tilt: Standard
