MFS 20

Powerful, yet lightweight, the 20 hp is a great choice for many boaters. You can expect this model to deliver the same level of performance that our other engines deliver. Plus with the low maintenance, fuel efficiency and durability of this 20hp why wouldy ou look anywhere else? Try the new 20 hp for the ultimate boating experience because you don't deserve anything less! Power Tilt is available on many models. The 20 hp Power Tilt is ideal for inflatable, small fishing and pontoon boats. The uniquely designed engine improves functionality and convenience with its light and compact power tilt and transom bracket. Now you can tilt your motor out of the water with just a push of a button. Simplify your boating experience with a power tilt model.

Benefits Include:

  • Light and compact!
  • Designed with proven technology
  • Advanced cross-flow induction for smooth operation
  • Available in a wide variety of models
  • Canister style oil filter for easy replacement
  • Larger capacity oil reservoir for optimum lubrication
  • Tuned intake system for crisp takeoffs
  • Greatly reduced induction noise for a quieter ride
  • Trim tab reduces steering effort, functioning also as the sacrificial anode that protects the engine from electrolysis
  • Ultra Low emission, EPA and CARB approved
  • 5 Year limited warranty

High Performance and Easy Operation

  • Digital CD ignition for easier engine starting, quicker throttle response and smoother trolling
  • Recoil starter with larger reel making manual starting fast and easy
  • Large alternator and rectifier for superior battery charging*
  • Front mounted shift lever for easier operation
  • Remote control model available
  • Shallow water drive*
  • 6 trim positions*
  • Adjustable steering friction for reducing steering effort*

Fundamentals for User Convenience and Reliability:

  • Through-the-prop exhaust for a quieter ride
  • Thermostatically controlled cooling system for consistent engine temperature
  • Stainless steel water pump housing liner for outstanding durability
  • High grade marine aluminum alloy that provides the ultimate protection against corrosion
  • Zinc coating on internal water passages for superior corrosion resistance
  • 3.1 Gallon (12 liter) fuel tank includes fuel fittings and fuel line with fuel gauge on the cap
  • Aluminum propeller

Warning & Protection:

  • Low oil pressure warning (visual and audible**)
  • Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
  • Start-in-gear protection for safer engine starting
  • Over-rev. limiter

Technical Specifications

Engine (No. of Cylinder): 2
Output: 20 hp (14.7 kw)
Displacement: 351 cc (21.41 cu.in.)
Bore x Stroke: 61 x 60 mm (2.4 x 2.36 in)
Starting: Electric & Manual or Manual
Control Type: Remote Control or Tiller Handle
Gear Shift: Forward - Neutral - Reverse
Gear Ratio: 2.15:1
Propeller Selection Range: 6" - 10"
Transom Height: 15", 20"
Fuel: Unleaded Gasoline (87 Octane)
Oil Type: NMMA Certified FC-W® 4-stroke oil** SAE 10W-30/40 (SF, SG, SH, SJ)
Oil Capacity: 1 qt. (1000 mL)
Fuel Tank: 3.1 US Gal. (12 Lit) Separate Fuel Tank
Weight: 114.4 lbs. (52 kg)
Alternator Output: Optional: 12V, 145W, 12A (Standard on Electric Start Models)
Max. RPM Range: 5,400 - 6,100
Digital CD Ignition System: Standard
Start In Gear Protection: Standard
Thermostat Controlled Cooling System: Standard
Through-The-Prop Exhaust: Standard
Shallow Water Drive: Standard
Oil Pressure Warning: Standard
Power Trim and Tilt: Optional
