MFS 6

The 6 hp 4-stroke provides all the power you need for motoring in a small craft. This engine does that as well as providing fuel efficiency second to none and a redesigned carrying handle and holding grip make it convenient to transport! With all of this available at a competitive price, it is no wonder this little 6hp outboard receives so much attention and praise! The 6hp short & long shaft models are now available with either an Internal 0.3 gallon fuel tank (6CD model) or with an external 3.1 gallon fuel tank (6C model). The internal fuel tank model even includes a built-in external fuel connector so you can easily add an optional separate fuel tank. Sail Pro Model! Designed specifically for sail boaters. This powerful engine available in a "long" and an "ultra-long" shaft, has a high thrust sail drive propeller to give you the power you need. It also includes a 12V, 60W, 5A charging system for charging your battery or powering external electrical devices and its own charging cable. Sailing just got better with Tohatsu's 6hp Sail Pro!

Benefits Include:

  • Light and compact!
  • Front mounted shift lever, an industry first in its class!
  • Designed with proven technology
  • Greatly reduced vibration for smooth and stable running at all speeds
  • Greatly reduced induction noise for a quieter ride
  • Ultra-low emission, EPA and CARB 3-Star rating approved
  • 5 Year limited warranty

Easy Operation and Handling:

  • Digital CD ignition for easier engine starting, quicker throttle response and smoother trolling
  • Recoil starter with larger reel making manual starting fast and easy
  • Shallow water drive
  • 6 trim positions
  • Adjustable steering friction for reducing steering effort
  • New longer tiller handle (110mm extension)
  • Newly designed holding grip and larger carrying handle

Fundamentals for User Convenience and Reliability:

  • Through-the-prop exhaust for a quieter ride
  • Thermostatically controlled cooling system for consistent engine temperature
  • Stainless steel water pump housing liner for outstanding durability
  • High grade marine aluminum alloy that provides the ultimate protection against corrosion
  • Zinc coating on internal water passages for superior corrosion resistance
  • 3.1 Gallon (12 liter) fuel tank with fuel gauge (standard on external fuel tank models only)
  • Aluminum propeller

Protection:

  • Low oil pressure indicator
  • Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
  • Start-in-gear protection for safer engine starting
  • Over-rev. limiter

Technical Specifications

Engine (No. of Cylinder): 1
Output: 6 hp (4.4 kw)
Displacement: 123 cc (7.5 cu.in.)
Bore x Stroke: 59 x 45 mm (2.32 x 1.77 in)
Starting: Manual
Control Type: Tiller Handle
Gear Shift: Forward - Neutral - Reverse
Gear Ratio: 2.15:1
Propeller Selection Range: 6" - 9"
Transom Height: 15", 20", 25"
Fuel: Unleaded Gasoline (87 Octane)
Oil Type: NMMA Certified FC-W® 4-stroke oil** SAE 10W-30/40 (SF, SG, SH, SJ)
Oil Capacity: 15 fl. oz. (450 mL)
Fuel Tank: Internal Fuel Tank Models (MFS6CD) : 0.29 US Gal. (1.1 Lit) Integral Tank (Includes an External Fuel Tank Connector installed on engine to allow user to use an optional external fuel tank) External Fuel Tank Models (MFS6C) : 3.1 US Gal. (12 Lit) Separate Fuel Tank
Weight: 55 lbs. (25 kg)
Alternator Output: Optional: 12V, 60W, 5A (Standard on "Sail Pro" models)
Max. RPM Range: 5,000 - 6,000
Digital CD Ignition System: Standard
Start In Gear Protection: Standard
Thermostat Controlled Cooling System: Standard
Through-The-Prop Exhaust: Standard
Shallow Water Drive: Standard
Oil Pressure Warning: Standard
